ZEBRONICS 8 Channel CCTV Power Supply (ZEB-ISPS8CH)
In stock
ZEBRONICS ZEB-ISPS8CH CCTV Power Supply delivers stable 12V DC power output for up to 8 surveillance cameras with reliable safety protection. Designed with LED indicators, selectable voltage ranges, and compact durable construction for professional CCTV installations.
Specification
Value
Product Type
CCTV Camera SMPS Power Supply
Brand
ZEBRONICS
Model
ZEB-ISPS8CH
Input Voltage Range
AC 100V-240V
Input Frequency
50Hz / 60Hz
Input Current
0.75A
Output Voltage
DC 12V
Output Current
4.2A
Maximum Power Output
50W
Number of Channels
8 Channel
CCTV Camera Support
Up to 8 Cameras
Ripple
<500mV
Hold-Up Time
16 ms
Turn-On Delay Time
2 Seconds
Rise & Fall Time
20 ms
Output Voltage Range Normal
11.60V – 12.60V
Output Voltage Range Medium
12.40V – 13.40V
Output Voltage Range High
13.40V – 14.40V
Overload Protection
Yes
Over Voltage Protection
Yes
Short Circuit Protection
Yes
Over Temperature Protection
Yes
LED Indicator Support
Yes
Input Terminals
8-tail Socket
Output Terminals
European Terminal
Enclosure Material
Plastic
Operating Temperature
-10°C to 50°C
Storage Temperature
-10°C to 50°C
Product Dimensions
14.32 × 10.8 × 3.42 cm
Package Contents
Power Supply Unit & 1 Meter Power Cord
