AVMatrix SC2030 3G-SDI/HDMI Scaling Cross Converter
In stock
Compact HDMI/SDI cross converter with scaling, frame rate conversion, and audio embedding for professional video signal conversion.
| Specification |
Details |
| Video Inputs |
1 × HDMI, 1 × 3G-SDI |
| Video Outputs |
1 × HDMI, 2 × 3G-SDI |
| Audio Input |
1 × 3.5mm Analog Audio |
| Supported Resolution |
Up to 1080p60 |
| Scaling |
Up/Down Scaling Supported |
| Frame Rate Conversion |
Yes |
| Audio Embedding |
Yes (HDMI & SDI Output) |
| Control Options |
DIP Switches + PC Software (USB) |
| USB Interface |
Micro-USB (Power, Control, Firmware) |
| Video Standards |
SMPTE 259M / 292M / 424M |
| Power Consumption |
Approx. 4W |
| Build Type |
Compact Metal Body |
| Dimensions |
125.5 × 104 × 24.5 mm |
| Weight |
Approx. 485 g |
| Operating Temperature |
-20°C to 60°C |
| Warranty |
3 Year Manufacturer Warranty |
